KTP 99 WLC PS

KTP 99 WLC PS

For 3Ø Pressure Booster Pumpset

Three Phase DOL Pump Starter Controller
with Water Level Controller for Pressure Switch Applications

KTP 99 WLC PS product

Features & Benefits

Starter

Electronic starter (Relay Based 40 Amp. / Phase)

Display

Seven Segment Display - Digital Voltmeter & Ammeter

Protections

Phase Failure (Supply Side / Motor Side)
Reverse Phase, Voltage & Current Unbalance
Overload / Over Current (Site Settable)
Dryrun / Under Current (Site Settable)
High/Low Voltage (Site Settable)
Extreme High Current

Timer

Power ON Timer
Dryrun Autostart Timer (Site Settable: Off-1-999 min)
Cyclic ON - OFF Timer (Site Settable: Off-1-999 min)
Toggle Timer (Site Settable: Off - 1 - 999 min)

Technology

Microcontroller Software Technology Embedded Controller

Settings

One touch Pump Current Settings
Automatic Protection Settings

Others

Facility to connect Pressure Switch / Float Switch for Automatic Water Level Control for Tap Feeding / Tank Filling applications

LED Indications

Power / Pump ON
SPP/CUB / RP
OC/Overload
UC / Dryrun
LT Empty
UTF / PS
Current
Timer

Switches

ON / Set PC
OFF / Reset
Auto / Manual
Float Auto / Bypass
Setting / Accept

Applications

Constant pressure water supply systems
Booster pump systems in buildings
Industrial water pressure control
Tap feeding commercial projects

Suitable for Pumpset

Vertical & horizontal multistage pumpset
Vertical & horizontal inline pumpset
Centrifugal monoblock pumpset
Submersible booster pumpset

Technical Specifications

Power Rating: 0.5 - 7.5 HP
Phase: Three
Rated Voltage: 440V
Frequency: 50Hz
Voltage Range: 280 - 500V
Max. Current: 16A

Catalogue

KTP 99 WLC PS
