KPM 11 TTC

KPM 11 TTC

For 1Ø Openwell Submersible Pumpset

Single Phase Openwell Submersible Pump Starter
Controller with Start, Run Capacitor and Water Level Controller

KPM 11 TTC product

Features & Benefits

Starter

Electronic starter (Relay Based 40 Amp.)

Display

Seven Segment Display - Digital Voltmeter & Ammeter

Protections

Overload / Over Current (Site Settable)
Dry Run / Under Current (Site Settable)
High / Low Voltage (Site Settable)
Extreme High Current

Timer

Power ON Timer

Technology

Microcontroller Software Technology Embedded Controller

Settings

One-touch Pump Current Settings
Automatic Protection Settings
Password Protection for Settings

Others

Two tank fully automatic Water Level Controller
Facility to connect Float Switch / Level Sensors / Magnetic Switch etc

Switches

Value Setting (4 Switches)
ON / OFF
Over Current
Under Current
Auto
Manual

Applications

Underground tank to overhead tank water transfer
Water supply to single / multiple overhead tanks
Domestic and community water supply
Gardening and small farm irrigation

Suitable for Pumpset

Openwell submersible pumpset
Any pumpset with start & run capacitor requirements

Technical Specifications

Power Rating: 0.5 - 2.0 HP
Phase: Single
Rated Voltage: 220V
Frequency: 50Hz
Voltage Range: 130 - 280V
Max. Current: 20A
