KCD 122

KCD 122

For Agitator & Dosing Pump Systems

Agitator & Dosing Pump Controller
(One Working & One Standby)

KCD 111 product

Features & Benefits

Starter

Electronic starter (Relay Based 40 Amp.)

Display

Seven Segment Display - Digital Voltmeter & Ammeter

Timer

Power ON Timer
Cyclic ON - OFF Timer (Site Settable: Off - 1 - 999 min)

Technology

Microcontroller Software Technology Embedded Controller

Settings

One touch Pump Current Settings
Automatic Protection Settings

Others

Fully automatic Water Level Controller
Facility to connect Float Switch etc

LED Indications

Healthy
Agitator ON
Agitator OFF
Timer
LT Empty
Dosing 1
UT Full
Dosing 2

Switches

Agitator ON
Agitator OFF
Dosing ON / Dosing OFF
Dosing 1 ON / Dosing 2 ON / Alternate
Setting / Accept

Applications

Water treatment
Agriculture / horticulture
Industrial applications
Swimming pools
Sewage / effluent treatment

Suitable for Pumpset

Chemical dosing pump
Chemical injection pump
Agitator / brine mixer

Technical Specifications

Power Rating: 0.5 - 3.0 HP
Phase: Single
Rated Voltage: 220V
Frequency: 50Hz
Voltage Range: 130 - 280V
Max. Current: 20A

Catalogue

KCD 122
